Teltonika 5G COMBO MOBILE/GNSS SMA ANTENNA

Technical Data

Mounting type

M6 Screw or Adhesive

Enclosure material

PC/PC+ABS

UV resistant

?

Cable length

3000 mm

Weight

450 g

Operating temperature

• 40 °C ~ +80 °C

Operating humidity

? 90 %

Ingress Protection Rating

IP67

RoHS compliant

?

5G MOBILE MIMO ANTENNA

Frequency range

600 ~ 960, 1427 ~ 2700, 3300 ~ 4200, 4400 ~ 5000 MHz

Polarisation

Linear

Radiation pattern type

Omni-directional

Gain

? 4 dBi

V.S.W.R

? 2.5

Impedance

50 ?

Connector type and count

4 x SMA Male

Cable type

4 x LMR100

GNSS ANTENNA

Frequency range

1559 ~ 1610, 1164 ~ 1189 MHz

Polarisation

RHCP

Radiation pattern type

Directional

Gain

? 2 dBi

LNA Gain

17 ± 2 dB

LNA noise figure

? 2 dB

V.S.W.R

? 2

Impedance

50 ?

Supply voltage

3 ~ 5 VDC

Current consumption

15 mA

Connector type and count

1 x SMA Male

Cable type

1 x LMR100
